Strain Gauge Rotary Torque Sensor with Capacity 0-1000Nm ，and A Torque Value Display and A Speed Display

Rated Load :0-1000 NmSensitivity :1.5±10% mV / VZero Output :±1%F.SNon-linearity :±0.1, 0.3% F.S.Hysteresis :±0.05% F.S.Repeatablity :±0.05% F.S. Creep :±0.03% F.S/30minTemp. effect on span (%F.S/10): 0.03F.S/10Temp. effect on zero (%F.S/10): 0.03%F.S/10Input resistance () :350,750±10Output resistance () :350,700±5Response Frequency : 100SInsulation resistance (M) : 5000M/100VVoltage (V) : 10VDC(9-15VDC)Compensated Temperature Range :-10-60 Use Temperature Range :-20-65Safe overload (%F.S) : 150%F.SLimit overload (%F.S) : 200%F.SCable Size : Ø5.2×3mMode of Connection : Red /E+,Black /E-,Green /S+,White /S-Material :Stainless Steel. Steel Alloy, Aluminum

• Application:It can be applied to torque;rotary speed;power measurement of AC;DC motor; gear motor for a long-term; can measure both forward and reverse torque
• Stability: Can be used stably for a long time
• Small size:Compact and space saving
• Flexible installation: compact size and versatile mounting options; fits into confined spaces or complex machinery
• After-sales service support: If you have any questions； I will answer them as soon as possible
